Type HGX

Type HGX
Type HGX
Product Code : 02
Product Description

Type HGX

HGX Series pumps are the most efficient and economic range of flange and foot mounting type positive displacement rotary gear pump. HGX series pumps have single helical shrink fitted gear pair and hardened and grind finished shaft. Ultra bronze sintered bushes ensured smooth running. It is perfectly designed and constructed, which increases the life and performance of pump. The suction and delivery connections are available in sizes from 1/4″ to 1 ½”. These pumps can be operated up to pressures of 10 kg/cm² with 2.5 LPM to 125 LPM flow capacity. These pumps are designed to run at 1440 RPM and suitable for use with liquids up to viscosity of 50,000 SSU and a maximum temperature of 200ºC.



General Description HGX series pumps are foot mounted with ‘L’ bracket or Flange mounted general purpose pumps having threaded inlet & outlet ports.
Material of Construction Pump Body: CI
Gears: Alloy Steel- single Helical.
Shaft : Alloy Steel-Hardened & Ground.
Bush: Self Lubricated Sintered Bronze Bushes.
Sealing: Oil Seal.
Sizes 1/4 ” to 2 ½” BSP (8 different sizes) 2.5 to 350 LPM.
Capacity 2.5 to 350 LPM.
Pressure Upto 12 kg/cm2.
Features Sturdy design and construction to ensure long trouble free life with best performance.
Applications All General Purpose Viscous fluid like Lub Oil, Paints, Transformer Oil, LDO
