Home » Products » AC MOTORS LOW VOLTAGE » Wound Open Type

Wound Open Type

Wound Open Type
Wound Open Type
Product Code : 05
Brand Name : NEW INDIA ELECTRICALS LTD.
Trade Information
  • Minimum Order Quantity
  • 10
  • Unit of Measure
  • Piece/Pieces
  • Payment Terms
  • Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Paypal, Others
  • Packaging Details
  • BOX
  • Main Export Market(s)
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • Main Domestic Market
  • All India
Product Description

Wound Open Type

New India offers Low Voltage Slip Ring electric motors ranging from 3.7 kW to 350 kW in Open (Drip Proof – IP23) construction. These motors are designed with Slip Ring and Brush Gear arrangement for trouble free operations and long lasting brush life. Slip Rings are moulded in epoxy-based insulation and have excellent stability in operation at high temperatures with excellent anti-tracking property. Motors are designed especially for applications with high inertia loads. It has Reliable, Rugged design and Construction. Motors are suitable for starting with external resistance in motor circuit. Applications include Fans, Compressors, Mixing and Rotary Mills, Crushers and Pulverizers.Motors comply to IS standards. Specially designed motors are offered with IPSS standards to meet the requirements of Steel Plants.

Range
Output Range(KW) 7.5 to 350
Pole 4/6/8/10
Frame Size 160 to 400
Rotor Type Wound
Voltage(V) 380/415/550
Frequency(Hz) 50/60
Insulation F/H
Enclosure IP23
Cooling IC01
Mounting IB3(Foot)/B5(Flange) B35(Foot Cum Flange)
Standards IEC:34-1/IS:325
Applications
Mixing and Rotory Mills
Fans
Compressors
Crushers
Pulverisors
Salient Features
Designed specially for applications with high inertia loads.
Reliable Rugged design and Construction.
Low Noise and Vibration.
Optimum fan design for better cooling.
Suitable for Direct/Belt Driven Applications.
Bi-Directional Rotation.
Rigidly sealed Terminal box.
Suitable for starting with external resistance in motor circuit.
