HGSX Type Gear Pump

HGSX Type Gear Pump

Product Details:

  • Supply Ability : 10 Piece Per Day
5000 INR/Piece

Price And Quantity

  • 5000 INR/Piece
  • 1 Piece
  • 5000.00 - 10000.00 INR/Piece

Trade Information

  • 10 Piece Per Day
  • 1 Week
  • All India

Product Description


HGSX Series pumps are self priming, foot mounting type positive displacement rotary gear pump. HGSX Series are all Stainless Steel (SS-316) in three piece construction with investment cast. Due to its three piece construction, it is easily cleanable and maintainable. It is widely used in all kind of food industries due to these qualities. These pumps have SS-316 Gear and shaft that are nitrated to give long life and trouble free performance. The shaft is supported on self lubricating type  coated  Bushes and the sealing is done with based "GFO" pack sealant which gives zero leakage. The right angle mounting brackets facilitate foot mounting of the pump on base plate with Electric Motor of appropriate ratings. These pumps have sturdy design and construction for long trouble free service. The suction and delivery connection are available in 1/4" to 2"  size. These pumps can be operated up to pressure of 10 kg/cm with 8.33 LPM to 300 LPM flow capacity and has suction lift of 1m to 5m at rated speed of 1440 RPM. These pumps are designed to handle maximum Viscosity of 100000 SSU and maximum temperature of 200ºC.

General Description

HGSX series pumps are Special purpose foot mounted pumps with threaded inlet & outlet ports.

Material of Construction

Pump Body: SS-316 (investment Casting).
Gears: AISI- SS 316 (H. Nitrided)  single Helical Gear.
Shaft: AISI- SS 316 (H. Nitrided & Ground). Bush : coated imported .
Sealing :  base 1/4.


1/4 "Zpack  to 2 (6 different sizes)


8 to 300 LPM.


Liquid Upto 11 kg/cm2.


Easily cleanable.


All food Grade products like Ghee, Butter, Glycol, Glycerine, Corrosive Viscous Chemicals.
